L-36” x W-72” x H-60”
Machine Dimension950 Kgs. approx.
Machine WeightHIPS, PVC, ABS, PET
Material Used16” x 24”
Forming Area| Sl. No. | MODEL | STF-S&B |
|---|---|---|
| 1 | Forming Area | 16” x 24” |
| 2 | Electricals & Switch | Make - L&T |
| 3 | Vacuum Pump | 300 to 500 LMV |
| 4 | Heat Control | Sunvic |
| 5 | Electric Load | 10 kw. |
| 6 | Sheet Thickness | 0.10 to 2.5 mm. |
| 7 | Material Used | HIPS, PVC, ABS, PET |
| 8 | Heating Element | Tublar Air Heater - ISI Make |
| 9 | Motor | 2HP Make - ABB |
| 10 | Limit Switch | Make - Siemens |
| 11 | Cylinder Operation | Pneumatic Valve Control |
| 12 | Machine Dimension | L-36” x W-72” x H-60” |
| 13 | Machine Weight | 950 Kgs. ( Approx.) |
| 14 | Maximum Draw | 100 mm. |
