Thermoforming Glass Machine

Request Callback
Schedule a Demo
Ask for Price

Technical Specifications

Sl. No. PLANT MODEL Unit STF-TFM 300 x 550 STF-TFM 350 x 650
1 Material Sheet HIPS, PP, PET HIPS, PP, PET, PLA Biodegradable
2 Sheet Width Range mm. 300 x 550 350 x 650
3 Sheet Thickness Range mm. 0.30 to 1.50 0.30 to 1.50
4 Die Area mm. 300 x 550 350 x 650
5 Bed Size mm. 350 x 850 350 x950
6 Die Mounting mm. 300 x 600 300 x 600
7 Max. Speed Aprox. Cycle/mm. HIPS 35 / PP 30 HIPS 40 / PP 35
08 Max. Draw Depth mm. 100 120
9 Motor Drive (Ac) kw. 10 HP-ABB 15 HP-ABB
10 Top Heating Load kw. 31 kw. / 48 Heaters 35 kw. / 54 Heaters
11 Bottom Heating Load kw. 26 kw. / 40 Heaters 29 kw. / 45 Heaters
12 Running Load kw. 70 kw. 76 kw.
13 Control Panel Dimension inch L-124” x W-46” x H-70” L-126” x W-48” x H-71”
14 Machine Dimension inch L-150” x W-120” x H-110” L-170” x W-150” x H-120”
15 Approx. Weight in kgs. 3600kgs. 4100kgs.
16 Running Load 10 kw.
17 Machine Dimension L-100” x W-52” x H-64”
18 Control Panel Dimension (LxWxH) L-16” x W-36” x H-50”
19 Machine Weight 1500 Kgs Approx
20 Machine Doors, Panel, Frame & Parts Powder Coated
Delivery: 90 days after confirmation of order
