600 to 650 mm.
Maximum Useable Sheet Width0.22 to 1.5 mm.
Average ThicknessCeramic
Heaters TypesGreaves /Elecon
Helical Gearbox| Sl. No. | PLANT MODEL | STF-T-DIE - 75 | STF-BSM - 90 |
|---|---|---|---|
| 01 | Screw (Dia) | 75 mm. | 90 mm. |
| 02 | LD Ratio | 30 : 1 | 32 : 1 |
| 03 | Maximum Useable Sheet Width | 600 to 650 mm. | 600 to 650 mm. |
| 04 | Average Thickness | 0.22 to 1.5 mm. | 0.22 to 1.5 mm. |
| 05 | Types of Material Used | PP, HIPS | PP, HIPS |
| 06 | Production Capacity | 120-125 kg./h | 200-230kg./h |
| 07 | Heaters Types | Ceramic | Ceramic |
| 08 | Helical Gearbox | Greaves / Elecon | Greaves / Elecon |
| 09 | Screen Changer | Rajhans | Rajhans |
| 10 | Motor & Drive | 40HP, AC. (ABB / Cromption) | 60HP, AC. (ABB / Cromption) |
| 11 | Machine Weight | 4000 Kgs approx | 4800 Kgs approx |
