156” x 48” x 81”
Machine Dimension (LxWxH)3000kg Approx
WeightHIPS, PVC, PET
Material Used600 x 600 mm
Forming Area| Sl. No. | MODEL | STF-OVFM Online |
|---|---|---|
| 1 | Forming Area | 600 mm. x 600 mm. |
| 2 | Chain Movement Duplax | Servo Motor Delta |
| 3 | Vacuum Pump | 500LMV with Vacuum Tank |
| 4 | Heating Elements | Ceramic, Make - Hi Heat England |
| 5 | Motor - 2 HP | Make - ABB |
| 6 | Machine Control | PLC |
| 7 | Material Used | HIPS, PVC, PET |
| 8 | Electric Load | 20 kw. |
| 9 | Cutting - Hydraulic | 600mm. x 600mm. |
| 10 | Capacity (Force) | 50 Ton |
| 11 | Oil Tank Capacity | 100 Ltrs. |
| 12 | Machine Weight | 3000kg Approx |
| 13 | Timer Switch, Electric Control Panel | Make - L&T |
| 14 | Machine Dimension (LxWxH) | 156” x 48” x 81” |
| 15 | Control Panel Dimension (LxWxH) | 36” x 16” x 50" |
